Thin 10-Step Block, Metric (1-10mm)

Price: $1,289.00
Part Number:
THIN10STEP.MCS
Availability:
In Stock
Bulk Pricing:
Buy in bulk and save
Certification Report:
Included ?
Included Documentation
Every PH Tool Test Block and Reference Standard ships with:
- NIST-traceable Certification Report stating conformance to applicable specification(s)
- Material Test Report for traceability of specific heat/lot of raw material used (PH Tool material only)
- PMI Report showing results of chemical analysis via XRF testing (PH Tool material only)
Optional Documentation
- Customers have the option to purchase a Full-Dimensional Inspection Report showing all of the As-built dimensions of the block at additional cost.

Description

Note:

1018 Steel Version is Nickel-plated

7075-T6 Aluminum Version is soft anodized, clear

Special step block for thickness and linearity calibration. The Thin 10-Step metric version is made to meet PH Tool Drawing No. 10598 and goes from 1mm to 10mm in 1mm increments. Face measures 20mm; x 20mm.

Metric

• Fitted wooden storage case optional...see above.
